Found it !! My 'Royal Bride' restoration thread

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Tue May 14, 2013 8:25 pm

Stopped at the store on my way home from work. Had two versions playing in my head of how I would be making the fire pot. It depended on what materials I could buy and how much thy cost. Ended up going with the harder of the two, this because FRP is only available in full sheets.
Enjoy
Last edited by Wanna Bee on Tue May 14, 2013 8:40 pm, edited 1 time in total.
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Tue May 14, 2013 8:27 pm

Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Poconoeagle On: Tue May 14, 2013 8:38 pm

Dont ya think that fire pot will burn up with a hot coal fire in it :shock: :D ....

the pattern is taking shape 8-)
Poconoeagle

Stove/Furnace Make: Buckwalter & Co. , EFM520
Stove/Furnace Model: No. 28 Glenwood 1880, Alaska

Visit Hitzer Stoves

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Tue May 14, 2013 8:39 pm


Next move is to pop the forms out of the inside and put some Fiberglass in there. It looks like 2 layers of glass on each surface should give me the thickness I need. Before the 4th coat of glass and resin I will cut the teeth and cut it down to 6" overall high. That way I can coat everything with fiberglass to make the release easier. I will also be skim coating the outside with body filler for a flat clean finish.

Once I get that done it will get a quick shot of high gloss paint, checked for fix in the fully assembled stove , then dropped off for casting. Like I said easy like pie.
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Poconoeagle On: Tue May 14, 2013 8:42 pm

get out the wood burning tatoo gun and scribes yo name in it ! wannabee eye-ron works or somethin...... :lol:
Poconoeagle

Stove/Furnace Make: Buckwalter & Co. , EFM520
Stove/Furnace Model: No. 28 Glenwood 1880, Alaska

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Tue May 14, 2013 8:46 pm

Poconoeagle wrote:Dont ya think that fire pot will burn up with a hot coal fire in it :shock: :D ....

I used 5/8" fire code GWB for the form. That *censored* is UL tested. :P
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Tue May 14, 2013 8:54 pm

Poconoeagle wrote:get out the wood burning tatoo gun and scribes yo name in it ! wannabee eye-ron works or somethin...... :lol:



I have all intentions of popping a mold off of the rim where it is marked 14RB. Never though about doing anything custom on the outside. That, my friend could be dangerous.
Hmmm... What do I decorate my Fire pot with? :idea:



Jack-O-lantern?
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Poconoeagle On: Tue May 14, 2013 9:03 pm

The symbol in the coal addicts creed

Pick ax with " Bust some Nut" scrolled around it??? :oops:

Pick ax's criss-crossed over a coal hod...

B.R.A. Club??? ( black rocks anonymous )....... 8-)
Poconoeagle

Stove/Furnace Make: Buckwalter & Co. , EFM520
Stove/Furnace Model: No. 28 Glenwood 1880, Alaska

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: dcrane On: Tue May 14, 2013 9:30 pm

Newbie... I bow to you my friend :notworthy: You and I both know what your doing is more then most would or could do and I ditto the reccomendation of your name on the casting but it should be done in a raised form, you can obtain rubber, wood, plastic lettering online that can be secured to your mold for pennies...go for it bro! you deserve it :clap:
dcrane

Hand Fed Coal Stove: Crane 404

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Tue May 14, 2013 10:20 pm


Not to bad for the rough pattern. I need to sand a few high spots on the "rim" before applying any more glass.

Doug,
Thanks for the kind words. I Have a huge respect for the craftsmen of the past. I am only replacing/replicating something that a man created a long time ago.


On a serious note I can't do anything on the outside of the FP, there is no way it would release from the sand to make the mold.
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: franco b On: Tue May 14, 2013 10:58 pm

Wanna Bee wrote: Like I said easy like pie.

By golly you were right, just like I have noticed, It's always easy as long as somebody else does it.

Congratulations, clever and nice work.
franco b

Hand Fed Coal Stove: V ermont Castings 2310, Franco Belge 262
Baseburners & Antiques: Glenwood Modern Oak 114
Coal Size/Type: nut and pea

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: dcrane On: Wed May 15, 2013 7:11 am

franco b wrote:
Wanna Bee wrote: Like I said easy like pie.

By golly you were right, just like I have noticed, It's always easy as long as somebody else does it.

Congratulations, clever and nice work.


LOL... Franco hit the nail on the head here! :lol:
dcrane

Hand Fed Coal Stove: Crane 404

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Thu May 16, 2013 2:58 pm

Cleaned up the inside and fiberglassed it.

After that it's time for a coat of body filler
2nd coat
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: Wanna Bee On: Thu May 16, 2013 3:07 pm

Turns out the reason someone painted the Finial gold is because... drum roll please. It was originally brass. I guess it's just easier to paint it than polish?
Next adventure will be to get the paint off without destroying it.


Look all of the green oxidation, this isn't cast iron.

Something tells me that this thing cost a bundle when it was new.

When this thing is finished it is going to be incredible. Because the top is brass I think brass hardware in the nickel will look great.
Wanna Bee

Stove/Furnace Make: Grander Stove Co.
Stove/Furnace Model: Royal Bride

Re: Found it !! My 'Royal Bride' restoration thread

PostBy: wsherrick On: Thu May 16, 2013 11:51 pm

Often times the brass was nickel plated, sometimes not. It's a matter of your personal taste.

According to the Catalog page, the 14 inch model was $51 bucks. That was quite expensive in the early 1890's when this stove was made.
wsherrick

Hand Fed Coal Stove: Glenwood Base Heater, Crawford Base Heater
Baseburners & Antiques: Crawford Base Heater, Glenwood, Stanley Argand
Coal Size/Type: Chestnut, Stove Size
